Features and Specs

Immediately update all your partners on project review results with the most compact large-format MFP. Intuitive, convenient print/scan/copy and HP DesignJet print quality help you communicate effectively and move the project forward.

This printer is intended to work only with cartridges that have a new or reused HP chip, and it uses dynamic security measures to block cartridges using a non-HP chip. Periodic firmware updates will maintain the effectiveness of these measures and block cartridges that previously worked. A reused HP chip enables the use of reused, remanufactured, and refilled cartridges.

Features:

COMMUNICATION – Immediately share meeting results

• Use built-in scanner to copy and distribute sketches and hand-annotated drawings to peers/partners right away.
• Easily link your computer, smartphone, or tablet to the printer with Wi-Fi Direct.
• Share drawings immediately – scan/email from front panel, use HP Smart app to email contacts, post to cloud.

CONVENIENT – Fast, agile, intuitive print/scan/copy

• Print documents fast – up to 26 seconds for A1 size prints.
• Enjoy easy installation in the office, construction job site with the most compact large-format MFP.
• Easily print project sets and PDF documents with HP Click printing software.

TRUSTED – HP DesignJet quality and reliability

• Get HP DesignJet quality also in small-format sizes – print half-size documents with 50 sheet A4/A3 input tray.
• Smart scanning technology protects originals from damage when scanning and obtains precise colours.
• Reinforced design and strong legs for easy transport and use at the job site.

Specs:

• Functions: Print, copy, scan
• Model size: 610 mm
• Print speed line drawing (economode, A1 plain paper): 81 A1 prints per hour
• Print speed: 26 sec/page on A1, 81 A1 prints per hour (Mechanical printing time)
• Print technology: HP Thermal Inkjet
• Printer drivers included: HP-GL/2, HP-RTL drivers for Windows; Raster driver for macOS and Windows
• Print quality color (best): Up to 2400 x 1200 optimised dpi
• Print languages: HP-GL/2, HP-RTL, TIFF, JPEG, CALS G4, URF
• Number of print cartridges: 4 (C, M, Y, mK)
• Ink types: Dye-based (C, M, Y); pigment-based (mK)
• Line accuracy: ±0.1%
• Maximum optical density (black): 8 L* min/2.10 D
• HP ePrint capability: Yes
• Connectivity, standard: Gigabit Ethernet (1000Base-T), Wi-Fi 802.11b/g/n
• Connectivity, optional: HP USB 3.0 to Gigabit LAN Adapter
• Network ready: Standard
• Memory: 1 GB
• Maximum Memory: 1 GB
• Internal Storage: None
• Finished output handling: Sheet feed, roll feed, input tray, media bin, automatic horizontal cutter
• Media sizes standard (metric rolls): 279 to 610 mm
• Media sizes, custom: Input tray: 210 x 279 to 330 x 482 mm; Manual feed: 330 x 482 to 610 x 1897 mm
• Media types: Bond and coated paper (bond, coated, heavyweight coated, recycled, plain, bright white), technical paper (natural tracing, vellum), film (clear, matte), photographic paper (satin, gloss, semigloss, premium, polypropylene), self-adhesive (adhesive, polypropylene)
• Media weight, recommended: 60 to 280 g/m² (roll/manual feed); 60 to 220 g/m² (input tray)
• Roll external diameter: 100 mm
• Media thickness: Up to 11.8 mil
• Scanner type: Sheetfed, CIS (Contact Image Sensor), media jam detection sensor, front feed scanning method
• Scan resolution, optical: Up to 600 dpi
• Enhanced scanning resolution: 600 dpi
• Bit depth: 24-bit/8-bit
• Scan size, maximum: 610 mm x 2.77 m
• Linear scan speed: Up to 3.81 cm/sec (colour, 200 dpi); Up to 11.43 cm/sec (greyscale, 200 dpi)
• Copy resolution (color text and graphics): Up to 600 x 600 dpi
• Copy reduce / enlarge settings: 50 to 400%
• Copies, maximum: Up to 99 copies
• Copier settings: Content type; Lighter/Darker; Background noise removal; Background colour removal; Blue print invert; Translucent media; Colour; Scan full width; Auto De-skew; Resize; Copy Margins; Quality
• Power: Input voltage (auto ranging): 100-240 V (±10%), 50/60 Hz (±3 Hz), 1.2 A max
• Power consumption: 35 watts (printing), 3.5 watts (sleep), 0.2 watts (standby)
• Energy star certified: Yes
• Operating temperature range: 5 to 40ºC
• Minimum dimensions (W x D x H): 1098 x 605 x 1155 mm
• Weight: 46.7 kg
• UPC number: 194850951664
• Package dimensions (W x D x H): 1310 x 570 x 645 mm
• Package weight: 65.7 kg

What's in the box: HP DesignJet T830 24-in MFP, printhead, ink cartridges, printer stand, spindle, quick reference guide, setup poster, startup software, power cord, refeed preventers

Software included: HP Click, HP Smart app, HP Support Assistant, HP Print Preview for Windows, HP DesignJet Utility for macOS and Windows

Manufacturer Warranty: One-year limited warranty. Warranty and support options vary by product, country and local legal requirements.
