Features and Specs

Designed to fit your office, budget, and the way you work, the world's smallest plotters provide outstanding simplicity. Send multiple files in just one click. Print your A1 plot as fast as 35 seconds. 500 MB memory.

This printer is intended to work only with cartridges that have a new or reused HP chip, and it uses dynamic security measures to block cartridges using a non-HP chip. Periodic firmware updates will maintain the effectiveness of these measures and block cartridges that previously worked. A reused HP chip enables the use of reused, remanufactured, and refilled cartridges

Features:

Extreme simplicity

Save time with the world's easiest job submission—send multiple files in one click with HP Click. Print with confidence you'll get the results you expect with an intuitive driver and true print preview. With an accessory option, print multi-size A3 and A1 projects without manually switching the media source.

Fits the way you work

Avoid waiting by the printer with high-speed printing as fast as 35 seconds per A1 plot. Be more productive—save time from job prep to final print by printing your projects up to 2X faster. Print your jobs and manage your plotter from virtually anywhere, anytime with the HP Smart app.

Fits your office and budget

Save space with the world's smallest plotters designed to fit your office. Use up to 95% less ink for routine maintenance vs competitor and get up to 100 extra A1 pages per month. More sustainable design reduces CO2e up to 7.3 tons/year by units sold by using up to 30% recycled plastic.

Specs:

• Functions: Print
• Model size: 610 mm
• Print speed: 35 sec/page on A1, 68 A1 prints per hour
• Print technology: HP Thermal Inkjet
• Printer drivers included: Raster driver for Windows and macOS
• Print quality color (best): Up to 2400 x 1200 optimised dpi
• Print languages: JPEG, URF
• Number of print cartridges: 4 (C, M, Y, K)
• Ink types: Dye-based (C, M, Y); pigment-based (K)
• Line accuracy: ±0.1%
• Maximum optical density (black): 8 L* min/2.10 D
• Connectivity, standard: Gigabit Ethernet (1000Base-T), Hi-Speed USB 2.0, Wi-Fi 802.11a/b/g/n, Wi-Fi Direct
• Memory: 512 MB
• Internal Storage: None
• Finished output handling: Sheet feed, roll feed, automatic horizontal cutter
• Media sizes standard (metric rolls): 279 to 610 mm
• Media sizes, custom: 210 x 279 to 610 x 1897 mm
• Media types: Bond and coated paper (bond, coated, heavyweight coated, plain, bright white, blueprint), technical paper (natural tracing), film (clear, matte), photographic paper (satin, gloss, semigloss, polypropylene), self-adhesive (adhesive, polypropylene)
• Media weight, recommended: 60 to 280 g/m²
• Roll external diameter: 100 mm
• Media thickness: Up to 11.8 mil
• Power: Input voltage (auto ranging): 100-240 V (±10%), 50/60 Hz (±3 Hz), 1200 mA max
• Power consumption: 35 W (printing), <5.6 W (ready), <2.1 W (sleep), <0.2 W (standby)
• Energy star certified: Yes
• Operating temperature range: 5 to 40ºC
• Minimum dimensions (W x D x H): 1013 x 440 x 285 mm
• Weight: 21.5 kg
• UPC number: 194850019715
• Package dimensions (W x D x H): 1155 x 575 x 405 mm
• Package weight: 28 g
• What's in the box: HP DesignJet T230 24-in Printer, printhead, introductory ink cartridges, spindle, quick reference guide, setup poster, power cord
• Software included: HP Click, HP Smart app, HP Print Preview for Windows, HP Easy Start, HP DesignJet Utility for Windows, HP Support Assistant
